Port Specifications
Number of 10/100/1000BASE-T ports - 5
Number of fixed LAN ports - 1
Number of fixed WAN ports - 1
System Specifications
CPU - Dual-core processor, 1.3 GHz clock frequency
Flash memory - 128 MB SPI NAND Flash
RAM - 512 MB DDR3
Wi-Fi Radio
Wi-Fi standard - Wi-Fi 6 (IEEE 802.11ax) standard, compatible with IEEE 802.11a/b/g/n/ac standards
Maximum wireless data rate - 2974 Mbps
Dimensions and Weight
- Product dimensions (W x D x H) - 283 mm x 172 mm x 46 mm (11.14 in. x 6.77 in. x 1.81 in.) (excluding the antennas and foot pads)
Weight - 1.2 kg (2.65 lbs.) (without packaging materials)
Environment and Reliability
Mounting options - Desk
Operating temperature - 0°C to 40°C (32°F to 104°F)
